POXURIO 8KW Diesel Air Heater User Manual

1. Ներածություն

Thank you for choosing the POXURIO 8KW Diesel Air Heater. This manual provides important information for the safe and effective operation, installation, and maintenance of your heater. Please read this manual thoroughly before use and retain it for future reference.

1.1. Անվտանգության տեղեկատվություն

• Օդափոխում: Always ensure adequate ventilation when operating the heater. The exhaust must be vented externally to prevent carbon monoxide buildup.
• Exhaust Pipe Safety: The exhaust pipe becomes extremely hot during operation. Ensure it is routed away from flammable materials and consider using a double-sided pipe or insulation (sold separately) to prevent fire hazards.
• Վառելիքի կառավարում. Use only diesel fuel. Handle fuel in a well-ventilated area and away from open flames or ignition sources.
• Էլեկտրական միացումներ. Ensure all electrical connections are secure and match the specified voltage (12V, 24V, or 110V/240V via adapter).
• Տեղադրում: Place the heater on a stable, non-flammable surface. Maintain a safe distance from walls, furniture, and other objects.
• Երեխաներ և կենդանիներ. Երեխաներին և ընտանի կենդանիներին հեռու պահեք գործող ջեռուցիչից։
• Բարելավված դիզայն. The 2025 upgraded design includes an internal thread and additional rubber ring to prevent oil leakage during travel and refueling, enhancing safety and longevity.

1.2. Heating Mechanism

The POXURIO Diesel Air Heater operates by drawing cold air through an inlet. This air then flows past a heated aluminum body, where it is warmed. The heated air is subsequently expelled from the air outlet, providing efficient heating for the desired space.

2. Փաթեթի բովանդակությունը

Upon unpacking, please verify that all the following components are included in your package:

• POXURIO 8KW Diesel Air Heater Unit
• Մոնտաժման հավաքածու (պտուտակներ, կլamps և այլն)
• Հեռակառավարման վահանակ (մարտկոցները ներառված են)
• Օդի զտիչ
• Օդի կափույր
• LCD Panel Control
• 100-125V Adapter (for 110V/240V power)
• Մուտքային խողովակ
• Արտանետվող խողովակ
• Խլացուցիչ
• DC12V/24V Power Cord
• Silent Oil Pump
• Օգտագործողի ձեռնարկ

3. Կարգավորման հրահանգներ

Follow these steps to set up your POXURIO Diesel Air Heater:

1. Տեղադրում: Position the heater on a flat, stable surface. Ensure there is sufficient clearance around the unit for proper airflow and safety.
2. Արտանետման համակարգի տեղադրում. Connect the exhaust pipe to the heater and route it securely to the outside environment. Ensure the exhaust is completely vented externally. If the provided exhaust pipe length is insufficient for your specific installation, an extension may be required (sold separately).
3. Օդի ընդունում. Connect the air inlet pipe and ensure it is clear of obstructions.
4. Վառելիքի միացում. Connect the silent oil pump to the heater and the fuel tank. Fill the 7L fuel tank with diesel fuel.
5. Էլեկտրաէներգիայի միացում. Connect the appropriate power source. The heater supports 12V, 24V, and 110V/240V. For 110V/240V operation, use the provided 100-125V adapter to plug into standard sockets. Ensure the power cord connector matches the heater's input.
6. Կառավարման վահանակ. Ensure the LCD control panel is securely connected.

4. Գործառնական հրահանգներ

The POXURIO Diesel Air Heater is designed for straightforward operation, offering quick heating and precise control.

4.1. Starting the Heater

• Միացում՝ Press the power button on the LCD control panel or the remote control to turn on the heater.
• Սկզբնական ջեռուցում. The heater will begin to warm up rapidly, reaching desired temperatures within approximately 5 minutes.

4.2. Ջերմաստիճանի վերահսկում

• LCD կառավարման վահանակ. Use the buttons on the LCD panel to adjust the desired temperature setting. The panel displays the current working status.
• Հեռակառավարման վահանակ. The included remote control allows for convenient adjustment of settings from up to 100 feet away. The remote is pre-paired from the factory.
• Ջերմաստիճանի միավորներ. The heater displays temperature in Celsius. To approximate Fahrenheit, multiply the Celsius setting by 3. For example, 21°C is approximately 63°F.

4.3. Ցածր աղմուկի աշխատանք

The heater features a low-noise fuel pump and operates at approximately 45dB, ensuring a quiet heating experience suitable for various environments, including sleeping areas.

4.4. High Altitude Performance

The POXURIO Diesel Air Heater has been tested for reliable operation at altitudes up to 6000 meters, making it suitable for use in low temperature or high altitude areas.

5. Պահպանում

Regular maintenance ensures the longevity and efficient operation of your diesel heater.

• Վառելիքի մոնիթորինգ. The 7L (1.85 GAL) fuel tank provides up to 24 hours of continuous heating, with a fuel consumption rate of 0.16-0.62 L/H. Regularly check the fuel level and refill as needed to prevent interruption of operation.
• Մաքրում: Periodically clean the exterior of the heater. Ensure air inlets and outlets are free from dust and debris.
• Պահպանում: When not in use, especially during off-season, store the diesel heater in its original packaging or a protective container in a dry, safe place.

6: Անսարքություն

If you encounter issues with your POXURIO Diesel Air Heater, refer to the following common troubleshooting tips:

• Ջեռուցիչը չի միանում.
  • Check power connection and ensure it is secure.
  • Verify fuel level in the tank.
  • Ensure the remote control batteries are functional if using the remote.
• Սխալի կոդերը LCD էկրանին. If the LCD displays an error code, consult the detailed user manual included in your package for specific code meanings and solutions.
• Անբավարար ջերմություն.
  • Check the temperature setting on the control panel.
  • Ensure air inlets and outlets are not blocked.
  • Verify the heater is appropriately sized for the space being heated (applicable range: 215-269 sq ft / 20-25 m²).
• Անսովոր աղմուկ. Ensure the heater is placed on a stable surface. Check for any loose components or obstructions in the fan area.

For issues not covered here, please refer to the comprehensive user manual provided with your product or contact POXURIO customer support.

7. Տեխնիկական պայմաններ

8. Երաշխիք և աջակցություն

For detailed warranty information, please refer to the warranty card included with your product or the full user manual. If you require technical support or have questions regarding your POXURIO Diesel Air Heater, please contact POXURIO customer service through the retailer where the product was purchased or visit the official POXURIO webկայքը կոնտակտային տեղեկատվության համար:
